Product Details
- Pre-pressurized diaphragm operation
- Maximum working pressure 100 psi.
- Lightweight, double drawn steel contruction
- Heavy Duty Parabolic diaphragm
- Corrosion resistant polymer base
- Powder coated exterior finish with high UV resistance
- Fused water chamber with powder coated interior
- NSF 612G/372 galvanized lead-free connection
- Projection welded air valve.
- 5-year limited warranty
A pump tank is an essential part of any well system. This State well tank delivers these benefits: it stores a supplemental water supply between pump cycles, reducing the number of pump cycles throughout the day increasing pump life. It maintains water pressure within your system.
Specifications
Tech Specs
Nominal Gallon Capacity
86 Gallons
Rated Storage Volume
86 Gallons
Power Source
DIAPHRAGM
Limited Tank Warranty
5 Years
Limited Parts Warranty
0 Years
Water Connection Location
BOTTOM
Water Connection Size
1.25"
ASME Certified
No
Destination Country
US
Installation Type
BOTH
Application
RESIDENTIAL
Shipping Height
59.25
Shipping Length
23.625
Shipping Width
23.625
Side Loop
No
Dimension & Venting
Type
Pump Tank
Height
59"
Width
23.375"
Shipping Weight
100 lbs
Product Literature
Technical Literature
